ASIAIR is a smart WiFi device that allows you to control all ASI USB 3.0 cameras, ASI Mini series cameras, and an equatorial mount to do plate solving and imaging with your Android phone, tablet or iPad when connected to ASIAIR via WiFi.
▶ Dual bandwidth WiFi Control
5G & 2.4G supported. you can switch between 5G & 2.4G depends on your environment.
5G is faster for downloading and not so crowded as 2.4G but works best over shorter distances without many obstructions such as walls.
▶ Independent Guiding & Imaging
Standalone guiding & Imaging without the need of PC. Everything is under control with your phone!
▶ Preview and focus in real time
Preview: with the help of WiFi network, ASIAIR can preview images in nearly real-time.
Debayer: debayer works for color cameras.
Auto white balance: AWB also works for color cameras
Focus: zoom a small area to provide max brightness curve and HFD curve, help users to get precise focus manually.
Auto & manually histogram stretching: screen stretching is always useful for dark deep sky imaging.
▶ Plate Solving
Offline plate solving can be done in a few seconds.
For those new to astro photograpy, here is little bit of explanation what plate solving is. It is a way of defining the actual direction of the telescope when an image has been taken. A camera takes an image of the night sky, then a software will analyze the star patterns and by comparing them with data from various star catalogues it will "understand" where it is pointed to. Then this information (usually repeated in various directions) can be used in various ways, but most frequently it is being used to calibrate / align the mount, so that you can use it to point at a subject of your choice without need for "star hopping", use of a finderscope, etc. It can also use this information to improve the pointing accuracy of the mount. Basically it's a very cool and useful feature.
ASIAIR can control your mount through INDI. iOptron and Sky-Watcher mounts were all tested with ASAIR by ZWO and you can find further info about compatibility of other mounts with INDI here on the INDI Mount support list: http://indilib.org/devices/telescopes.html
▶ SkySafari Bridge
The user can use the Skysafari app to control the mount through ASIAIR, choose the target and go.
▶ Supported cameras
ASI USB3.0 camera, ASI cooled camera, ASI mini cameras. (It can not support ASI120MM/MC camera)
ASIAIR comes with 4 USB2.0 ports, you can connect up to 4 USB devices and don’t need USB Hub.
ASIAIR need 5V@2.5A external power supply, it’s micro USB port. Normally, ASIAIR consumes only 500ma current. but peak value would be 2.5A, so please use the power cable come with ASIAIR. other cables may be too thin and cannot provide enough power. we also provide one 12V-5V DC Converter, so you can connect ASIAIR to the 12V power supply as most Astro device.
